Click here to see our featured product, Dixon’s new EZLink™ Armless Cam & Groove

DSC_0079

For nearly a half of a century, we have been one of the Midwest’s leaders in hose, conveyor belting and plastics. We supply products from some of the largest and most respected names in the industry such as Continental ContiTech, Flexco, Habasit, Aeroquip, Dixon, Röchling, Kanaflex, Kuriyama, Texcel and Reading Technologies. Working closely with both our customers and suppliers we strive to provide the safest, most efficient, and longest lasting solutions.

Dixon’s new EZLink™ Armless Cam and Groove Fittings
dixon-ezlink
Call us or Send us an email to find out more about this brand new product!

Applications:
• Transfer and/or unloading of fuels (gasoline or diesel) from tank truck to storage tanks
• Transfer of water and solutions compatible with aluminum and Buna-N rubber

Materials:
• Couplings and dust caps: A356 aluminum
• Coupler tabs and springs: 316 stainless steel
• Gasket: Buna-N

Features:
• Automatic couplers push-to-connect providing a reliable connection
• Coupler tabs cannot be pushed to disconnect when pressurized to 20 PSI or over
• Low profile allows easy connection and disconnection in tight applications
• Coupler push tabs can be locked with safety pins and/or zip tie

Specifications:
• Maximum working pressure with King Crimp™ ferrules
‣ 2″ – 250psi
‣ 3″ & 4″ – 150psi
• Maximum working pressure with crimp sleeves – 110psi
• Maximum working pressure with band clamps – 100psi
• Gasket temperature range: 5°F to 180°F


dixonvalve.com
