Conveyor Belt & Accessories
  • Heavy-Weight Conveyor Belt
  • Food Belting
  • Package & Bulk Handling Belt
  • Idlers
  • Belt Fasteners
  • Wing & Drum Pulleys
belt2-345x225
shutterstock_78362593-345x225
shutterstock_116265826-345x225
shutterstock_138904574-345x225

Heavy-Weight Conveyor Belt

Smith Industrial only uses a line of conveyor belt that is manufactured Tough and Tested Tough on over 70 miles to date in some of the most torturing applications…VIKING® PREMIUM Belt uses Premium Polyester/Nylon fabric in the belt carcass with a full 10 to 1 break strength for minimum stretch, maximum fastener retention, and superior load support.

  • 2 PLY 220 VIKING PREMIUM 3/16 x 1/16
  • 3 PLY 330 VIKING PREMIUM 3/16 x 1/16
  • 3 PLY 330 VIKING PREMIUM 1/4 x 1/16
  • 4 PLY 440 VIKING PREMIUM 1/4 x 1/16
  • 3 PLY 330 HOT VIKING 700 Degree 3/16 x1/16
  • 2 PLY 220 VIKING ASPHALT 350 Degree 3/16 x 1/16

“SHD” Heavy Duty Conveyor Belt: Designed and built exclusively from Smith Industrial Rubber & Plastics to compete with the most popular “Tier 2” belts as described by the Rubber Manufacturers Association.

The Grade II SBR/Natural PREMIUM rubber compound significantly exceeds RMA 2 specifications and even approaches RMA 1, which results in a “best buy” for handling abrasive materials like limestone, crushed rock, coal, sand, and gravel. Heavy rubber skims and high adhesion between plies team with a heavy overall gauge to make an exceptional impact resistant, long lasting conveyor belt.

quarry-600x300
recycling2-600x300

ROCKQUEST™ One & Two Ply I-Warp Conveyor Belt

VIKING™ ROCKQUEST One & Two Ply I-Warp belt’s reinforced carcass construction resists rips, tears and gouging caused by heavy impacts. These belts provide exceptional durability because of its tough synthetic carcass and heavy duty RMA Grade 1 covers (see below). It also has excellent bolt-holding capabilities for buckets and mechanical fasteners, a significant improvement over standard straight warp belts.

Recycling Industry

From off the shelf conveyor belts to made-to-order fabrications, our customers rely on our innovative solutions backed by our large inventory. Our MOR, Rip-Stop, PVC, Urethane, Heavy-Duty Black Belt, Eddy Current and Optical Sorter Belts are optimized for handling scrap metal, mulch, construction and demolition, E-Waste (computers, TVs, etc) and other products in a material refinery facility (MRFs). Our PVC conveyor belts are specially formulated for superior resistance to abrasion, rips, tears and gouging. With our versatile fabrications and ease of splicing, our designs will meet your small pulley requirements and demanding applications. This is a “best buy” for sorting recycled materials, handling cullet glass, metal stampings, and mechanical parts.

The Covers

•Superior Performance • Single/Multi-Ply • Hot Belt • Cleated Incline • Corrugated Sidewall

Grade 1Premium rubber compound. For conveyor belts with sharp, abrasive materials.
General Purpose Aggregates and above-ground mining operations.
Fire ResistantConveyor belt that is designed to MSHA standards for underground mining.
Fire / Oil ResistantDesigned for substances such as oil-treated coal in power plants, resistant to wear from oil and fire.
Moderate Oil Resistant Or “MOR”, recommended for wood chips or whole grains and other food or animal products with moderate oil substantive quality.
Super Oil Resistant
Or “SOR”, recommended for oil metal parts such as those found in recycling or manufacturing refinery facilities (“MRF”s), or for crushed soybeans and other materials where animal or vegetable fats are a deteriorating factor.
Ultra-GuardSpecifically engineered for whole grain products like wheat/cotton seed.
Moderate HeatResists hardening, cracking, & ozone up to 300 °F.
Heat ResistantConveyor belt resists hardening, cracking & ozone for 350-400 °F applications.
Oil / Heat Resistant Flexible belt even at 350 °F; this belt is specially designed for hot asphalt paving mix, oil extractor plants, etc.
SOR-FrPremium elastomer of SOR that also meets MSHA 2G flame retardant standards

Your toughest belting demands industrial strength resistance to oil, grease, vegetable acids and chemicals. They may need to operate at extremely high or low temperature — with low stretch, high fastener holding ability, and superior rip, tear and gouge resistance.

We’ve got you covered!

Food Belting
Our Food grade, USDA, FDA monofilament carcass is industrial grade and 100% synthetic. The monofilament provides for flat running and easy tracking with torsional rigidity. Single ply construction, there’s no cover or ply separation. Cleats and Lug S-Molded are available in white F.D.A or black oil-resistant nitrile compound, black SBR rubber, or black/white butyl. They are fully hot molded into the belt surface, not cold bonded or cemented on.

Package & Bulk Handling
Our PVC solid woven and Rubber rough top is the longest wearing most economical and least troublesome belting available on today’s belt market. Constructed of a single ply interwoven and a double ply carcass impregnated and covered with polyvinyl-chloride or SBR gum rubber. With resistance to moisture, rot, mildew, and wicking — our PVC conveyor belt and Rubber rough top is the standard for distribution centers and bulk handling centers.

logistics-852936_1920-350x225
Lightweight4-350x225
lightweightbelt2
lightweightbelt3
belt-1024x683-400x250
shutterstock_167801147-400x250

Don’t know what belt to use? Utilize our proprietary conveyor belt analysis software program.

Contact your Smith Industrial Conveyor belt salesman for on-site service to provide Conveyor Belt recommendations according to minimum motor horse power requirement, proper pulley diameters, proper counterweight specs, proper transition distances, and the actual surcharge angle.

Ultrasonic Gauge

A device to make precise cover gauge thickness measurements without destroying the belt. Contact your Smith Industrial salesman to set up an on-site survey with the Ultrasonic Gauge service. This provides the customer with estimated cover life, a window to replace a belt line, and a mechanism for scheduling minimized downtime.

Improve your conveyor system and equipment performance •

Reduce your spillage at loading and transfer points on conveyor belts with SBR skirtboard rubber and protect your equipment at the same time.
Abrasion and weather resistant for tough applications in all types of environments. Featuring 1,000 lb. tensile strength and 300% elongation in hardness of 55-60 durometer in gauge.

Sizes
1/4″, 3/8″, 1/2″, 3/4″ and 1″ Thickness
Cut from 50 ft. rolls, 4 inches to 12 inches wide
Also available in full slabs (48 inches wide x 50-ft. roll)

SBR Rubber, Gum Rubber, Urethane, PTFE/Teflon, UHMW, Other High Performance Polymers

Smith Industrial stocks for various chute, hopper, bin and cyclone separator service.

Wherever noise, abrasion, impact, sticking or bridging is a problem, Smith Industrial has the answer.

Materials

  • Redline (Red Natural Rubber Chute Lining)
  • Bondaline (Orange Natural Rubber Lining With Bonding)
  • RockRubber (Black Natural Rubber Lining With Bonding)
  • Urethane (Blue/Red Urethane Super Abrasion Resistant)
  • SuperSlide (White or Black HMW Polyethylene)
  • Economy (Black SBR/Natural Rubber)
chutelining2-300x100
chutelining1-300x100
skirtboardrubber-1-300x100

Belt Accessories

idler3-300x200
beltaccessories2-300x200
beltaccessories1-300x200

Idlers

Available in a wide variety of styles — troughing idlers, impact idlers, offset center roll idlers, live shaft rollers, self-aligning return idlers, channel-mount low profile, rubber cushion flat carrier, flat carrier idlers, rubber cushioned return idlers, return belt idlers, the 40 and 50 Series CEMA B Idlers, and more.

All idlers feature heavy duty foot brackets, external deflectors, rounded ends, quick change rolls, self-cleaning cross members, non-clogging centers, and a jig welded frame to ensure roll alignment.

Wing & Drum Pulleys

Any size drum and wing pulley in standard, heavy and mine duty manufactured right here in the USA for any applications you may have. Complete packages available including lagging, shaft and bearings.

Belt Fasteners

FLEXCO products, as well as other brands are available in a wide variety of styles: bolt hinged fasteners, Flexco scalloped edge fasteners, Bolt Solid Plate fasteners and VP to name a few.

Alligator® Staple• Available in stainless steel. Fastener sizes of #62, 125, 187, 310 to give PIW range of 100-250. Ideal lacing for light-and-medium weight belt, such as bulk-handling recycled materials.
Bolt Solid Plate •
Commonly used on higher-tension main haulage belts that are for highly abrasive materials such as sand, gravel and crushed stone. Specially formed teeth penetrate deep into the conveyor belt, without damaging carcass fibers.
Bolt Hinged • Ideal for applications requiring frequent belt-length alterations; the joints can be separated simply by removing the hinge pin. On-site installation requires only a portable hand or power tool.

Conveyor Accessories

FLEXCO ®, CONSHEAR ® and other top brands carried. We have a full line of belt cleaners, slider beds, skirt systems and rubber. Custom solutions offered with complete dust suppression systems for the pulp and paper industry.

A variety of cleaners offered are designed to deliver and maintain superior cleaning efficiency even on the most demanding, abusive belt lines. Our cleaners have tough carbide-tipped blades provide long wear life, high-performance cleaning and compatibility with mechanical splices.
